Broadband low profile 4G LTE, 4G & WiFi antenna, black, 704-960 & 1710-2690 MHz, 1m RG58, SMA male, 2.1 dBi – 80mm

Product Code: ZCG-EEH-L01-SMA


4 in stock

The ZCG-EEH-L01-SMA comes standard fitted with 1.0m RG58 and a gold plated SMA male. Being of a low profile design, this antenna antenna is suitable for situations where damage may occur or where space is at a premium. The ZCG-EEH-L01-SMA will improve mobile phone reception, wireless data transfer or any telemetry applications requiring all 4G LTE, 4G 3G and WiFi frequencies.

Frequency 704-960 MHz + 1710-2690 MHz - LTE, 4G, 3G and WiFi
Bandwidth Full frequency ranges stated
Gain 2.1 dBi at 704-960 MHz and 2.75 dBi at 1710-2690 MHz
Maximum Power 5 Watts
Impedance 50 Ohms
Polarisation Vertical
Construction Black ASA radome, chrome mount fittings, external cable and termination
Connector SMA male fitted to 1.0m RG58 cable
Tuning Factory at better than 2.7:1 VSWR
Dimensions Height: 80mm, Diameter: 42mm, Mount hole requirement: 16mm
