Product Code: 716DINFFM
$51.99
The 716DINFFM is a flange style mount 7/16" DIN female, low passive intermodulation (PIM) coaxial connector. The rear thread is a M3 male thread. The 716DINFFM is ideal for enclosure fitment or direct connection to your equipment utilising the M3 threaded centre conductor. The 716DINFFM has PIM3 performance of <-155dBc at 2 x 20W and is IP67 rated and RoHS 2002/95/EC compliant.
| Frequency | DC to maximum 7.5 GHz |
|---|---|
| Gain | Insertion loss: 0.8dB |
| Maximum Power | 3kW - peak |
| Impedance | 50 Ohms - nominal |
| Polarisation | Straight - flange mount |
| Construction | Tri-metal plated body, silver plated centre pin, PTFE insulator and silicone O-ring |
| Connector | 7/16" DIN female / 7/16" DINF / 716DINF |
| Tuning | 1.10:1 VSWR |
| Dimensions | Height: 32mm, Width: 32mm, Depth: 22mm |
