6 element round boom 4G cellular Yagi antenna, aluminium, 890-960 MHz, 50W, N-type female, 200mm cable, 9 dBd – 750mm

Product Code: Y806C-R


1 in stock

The Y806C-R 6 element round boom Yagi antenna is the ideal economical lower gain RF solution for directional lower 4G 890-960 MHz mobile phone improvement or as a wireless data link connections. The Y806C-R 4G Yagi antenna covers the 890-960MHz range for lower 4G, which is utilised by mutliple carriers, please check your local carrier frequencies to check compatibility.

Frequency 890-960 MHz - Lower 4G cellular mobile phone or ISM compatib
Bandwidth Full frequency range stated - 70 MHz
Gain 9 dBd
Maximum Power 50 Watts
Impedance 50 Ohms
Polarisation Mount horizontal or vertical as required - rotate to intende
Construction Welded aluminium boom, elements and folded dipole, 200mm external RG59 coaxial cable and N-female connector
Connector N-type female fitted to cable as standard or specify require
Tuning Factory at 1.5:1 VSWR
Dimensions Length: 750mm, Widest element: 210mm, Boom diameter: 25mm O.
