Product Code: ADP-8327
$17.94
On back order
The ADP-8327 is a FME female connector to TNC male connector, straight inter-series coaxial adaptor. The ADP-8327 FME female to TNC male adaptor is suitable for satellite communication systems or tranformation from a SMA male to TNC female requirements.
| Frequency | DC to maximum 11 GHz |
|---|---|
| Maximum Power | 25 Watts |
| Impedance | 50 Ohms - nominal |
| Polarisation | Straight - inter-series |
| Construction | Nickel plated body and nut, gold plated centre pin and PTFE insulator |
| Connector | SMA female and TNC male |
| Dimensions | Length: 25mm, TNC Diameter: 14mm, SMA Diameter: 6mm |
